Southco EA-R02 RF Wireless Remote Controller, 12V

Regular price $18.93 Sale

Add to Reorder List


Southco 82-19-240-16 DZUS\u00AE Lion Quarter-Turn Fasteners Southco remote control enables remote actuation of Southco electromechanical locks in a compact, economical package. The palm-sized RF transmitter communicates with an easily-placed receiver for convenient, hands-free locking and unlocking. A simple setup and installation ensure the easy transition from mechanical to electronic access. The EA-R02 is well suited to applications where remote access is needed, including transportation and industrial machinery. The unit includes the transmitter only. Industry applications includes transportation, industrial machinery and enclosures, exhibits/signs, furniture, vending machines. Proven 433 MHz radio frequency technology. Up to 4 transmitters per receiver. 8 meter (60 feet) unobstructed open air operating range. Auxiliary output for horn/light indicator output. ABS plastic material. Receiver power: 12V DC (+/-10 percent). Receiver standby current: 10mA maximum, no attached devices. Receiver operating current: 100mA maximum, no attached devices. Receiver outputs: three form C relays, rated 15A at 14V DC. Receiver lock/unlock output pulse duration: 250ms or 10 seconds (selectable). Receiver operating temperature: -20 to 80 degree C. Operating range: up to 60 feet/18 meters (open air). Operating frequency: 433.92MHz. Coding type: fixed code (24-Bit). Transmitter power: type CR2016 3VDC battery (quantity 2 per transmitter). Switch access tab, switch 1 - Used to enroll transmitters. Switch 2 - Used to set lock and unlock pulse duration. CE Certified.

Replaces the following:
  • Southco EA-R02-102
